User Manual

Nanoleaf Shapes

Warranty

Register your warranty and get the very best from your Nanoleaf.

It's below the barcode on the back of the Controller Unit.
As a new Nanoleaf owner, we want to make sure you get the most out of your masterpiece! Receive tips on how to use some exciting features, get exclusive offers, and be the first to know about new products. Don't want those? Unsubscribe at any time with the link in the footer of any email =)
All communications with you are handled in compliance with the Nanoleaf Privacy Policy, as is the treatment of any personally identifiable information provided. By submitting, you'll register your warranty (which will be emailed back to you) and you give us permission to contact you regarding warranty related issues. You will not be subscribed to other communications unless you've done so separately.

Thanks for registering your warranty!

Welcome to Smarter Living

Congratulations on becoming an official owner of the Nanoleaf Shapes. Remember, you can grow your setup with Expansion Packs to unleash your creativity to the fullest. Thank you for your support, you brighten our day like Nanoleaf brightens the world!

Product Overview
Product Setup

Slow down tiger! Before you mount your panels onto the wall, plug it in to a power source and try it out on a table or floor. Make sure your design fits into your space by measuring the width and height of your intended setup. For the best placement of your panels, please refer to Placement Recommendations. You can also use the tools below to help plan out your design!

What’s in the Box

7 Pack Starter Kit

13 Pack Starter Kit

3 Pack Expansion

20 Pack Expansion

7 Pack Starter Kit

13 Pack Starter Kit

3 Pack Expansion

25 Pack Expansion

5 Pack Starter Kit

10 Pack Expansion

Designing Your Layout

Layout Assistant

Explore different panel layouts with the Layout Assistant and preview them in your room using the AR feature. Download the Nanoleaf App and open the Layout Assistant to get started.

Flex Linkers

Extend the possibilities of your Nanoleaf Shapes even further! Bend around corners, mount the panels to angled surfaces, maybe even create something a little radical. Each linker bends 360 degrees, available on the Nanoleaf Shop.

Design Inspiration

Get inspired by the Nanoleaf community, check out our Social Media channels to see what other Nanoleaf owners are creating or explore the Nanoleaf Inspirations.

Show Off Your Design!

Remember to share your designs with us on social media by tagging @nanoleaf and #nanoleaf. Follow us to stay updated on upcoming giveaways, special promotions, and product updates.

Mounting Your Panels

1

Preparing Your Surface

The Nanoleaf Shapes should only be installed indoors and on a flat surface that can support the weight of the panels. Clean your surface to be free of dust, moisture and oil (1.1). The included Mounting Tape is NOT recommended for textured, popcorn, and porous surfaces (ie. wallpaper or brick walls) or for use on ceilings of any texture. (1.2).

2

Preparing Your First Panel

Designate a panel from your setup as the starting panel. Attach all needed linkers before you attach any panel to the wall.

3

Connecting the Controller & PSU

Connect your Controller and PSU into available linker slots of the first panel. Plug the other end of the PSU into a power source to ensure that your setup is on and properly connected as you continue to connect your panels together.

PSU Calculator

Make sure you have enough PSUs for your layout. Enter how many of each shape you have in your layout.

Please entry number

note: Each standard 42W PSU supports up to 21 hexagons (2W per panel), 28 triangles, or 78 mini triangles. Each Controller supports up to 500 of any shape. The Controller and PSU can be connected to any panel.

4

Mounting Your Panels

With a piece of tape, attach one adhesive side to the Mounting Plate at the back of the panel. Make sure to place it between the two holes on the plate, DO NOT cover them (4.1). Repeat the same process so that there are 2 pieces of tape on each plate (4.2). To mount, position your panel on your surface and use your fist to apply strong pressure to the center while rubbing in a circular motion for 30s (4.3.)

note: Make sure to leave end of the tape sticking out. This will allow you to safely remove them later from the wall.

5

Completing Your Setup

Attach all needed linkers before you mount the next panel to the wall. Continue to link each panel together and ensure that each panel lights up. Make sure the linkers are fully snapped onto the linker slot, the panels should be aligned edge to edge.

*

Need to Dismount Your Shapes?

Gently snap off the panel from the wall. The Mounting Plate will remain on the wall. With one hand on the Mounting Plate, use your other hand to pull the end of tape along the wall. Do not pull perpendicularly or at any other angle, otherwise you may damage your wall.

note: Need more Mounting Tape? Available for purchase Q3 2020.

1

Preparing Your Surface

The Nanoleaf Shapes should only be installed indoors and on a flat surface that can support the weight of the panels. Clean your surface to be free of dust, moisture and oil (1.1). The included Mounting Tape is NOT recommended for textured, popcorn, and porous surfaces (ie. wallpaper or brick walls) or for use on ceilings of any texture. (1.2).

2

Preparing Your First Panel

Designate a panel from your setup as the starting panel. Attach all needed linkers before you attach any panel to the wall.

3

Connecting the Controller & PSU

Connect your Controller and PSU into available linker slots of the first panel. Plug the other end of the PSU into a power source to ensure that your setup is on and properly connected as you continue to connect your panels together.

PSU Calculator

Make sure you have enough PSUs for your layout. Enter how many of each shape you have in your layout.

Please entry number

note: Each standard 42W PSU supports up to 21 hexagons (2W per panel). Each Controller supports up to 500 hexagons. The Controller and PSU can be connected to any panel.

4

Mounting Your Panels

With a piece of tape, attach one adhesive side to the Mounting Plate at the back of the panel. Make sure to place it between the two holes on the plate, DO NOT cover them (4.1). Repeat the same process so that there are 2 pieces of tape on each plate (4.2). To mount, position your panel on your surface and use your fist to apply strong pressure to the center while rubbing in a circular motion for 30s (4.3.)

note: Make sure to leave end of the tape sticking out. This will allow you to safely remove them later from the wall.

5

Completing Your Setup

Attach all needed linkers before you mount the next panel to the wall. Continue to link each panel together and ensure that each panel lights up. Make sure the linkers are fully snapped onto the linker slot, the panels should be aligned edge to edge.

*

Need to Dismount Your Shapes?

Gently snap off the panel from the wall. The Mounting Plate will remain on the wall. With one hand on the Mounting Plate, use your other hand to pull the end of tape along the wall. Do not pull perpendicularly or at any other angle, otherwise you may damage your wall.

note: Need more Mounting Tape? Available for purchase Q3 2020.

1

Preparing Your Surface

The Nanoleaf Shapes should only be installed indoors and on a flat surface that can support the weight of the panels. Clean your surface to be free of dust, moisture and oil (1.1). The included Mounting Tape is NOT recommended for textured, popcorn, and porous surfaces (ie. wallpaper or brick walls) or for use on ceilings of any texture. (1.2).

2

Preparing Your First Panel

Designate a panel from your setup as the starting panel. Attach all needed linkers before you attach any panel to the wall.

3

Connecting the Controller & PSU

Connect your Controller and PSU into available linker slots of the first panel. Plug the other end of the PSU into a power source to ensure that your setup is on and properly connected as you continue to connect your panels together.

PSU Calculator

Make sure you have enough PSUs for your layout. Enter how many of each shape you have in your layout.

Please entry number

note: Each standard 42W PSU supports up to 21 hexagons (2W per panel). Each Controller supports up to 500 hexagons. The Controller and PSU can be connected to any panel.

4

Mounting Your Panels

With a piece of tape, attach one adhesive side to the Mounting Plate at the back of the panel. Make sure to place it between the two holes on the plate, DO NOT cover them (4.1). Repeat the same process so that there are 2 pieces of tape on each plate (4.2). To mount, position your panel on your surface and use your fist to apply strong pressure to the center while rubbing in a circular motion for 30s (4.3.)

note: Make sure to leave end of the tape sticking out. This will allow you to safely remove them later from the wall.

5

Completing Your Setup

Attach all needed linkers before you mount the next panel to the wall. Continue to link each panel together and ensure that each panel lights up. Make sure the linkers are fully snapped onto the linker slot, the panels should be aligned edge to edge.

*

Need to Dismount Your Shapes?

Gently snap off the panel from the wall. The Mounting Plate will remain on the wall. With one hand on the Mounting Plate, use your other hand to pull the end of tape along the wall. Do not pull perpendicularly or at any other angle, otherwise you may damage your wall.

note: Need more Mounting Tape? Purchase from the Nanoleaf Shop USA.

Add to Your Masterpiece!

Be even more creative and grow your setup with Expansion Packs.

get one today

Pairing Your Panels iOS

Standard Pairing Process for iOS

To ensure a smooth pairing process, please make sure you have the following things ready:

  • Requires iOS 10+

  • Can be found on your Welcome Card, Controller or PSU.

  • 5 GHz networks are not compatible with Nanoleaf products.

  • The controller is ready when the Status LED is solid white.

1

Download and Open the Nanoleaf App

You can find the official Nanoleaf Smarter Series App in the App Store. Make sure you have the latest version.

2

Pair Your Shapes

  • 2.1

    Select the MORE tab.   · · ·

  • 2.2

    Select MY DEVICES and + to add a device.

  • 2.3

    Select SHAPES as your product and START PAIRING.

    NOTE: If you have more than one set of panels connected to your network, select the magnifying glass to identify the correct setup (it will flash green).

  • 2.4

    Once identified and selected, the camera will open.

  • 2.5

    Scan your pairing code to pair.

  • 2.6

    Your Nanoleaf Shapes should now be connected and ready to go!

*

Additional Pairing Method

  • 1. Select Don’t Have a Code or Can’t Scan?

    2. Enter your 8-digit pairing code (found on the Quick Start Guide, PSU or back of the Controller).

  • 1. After Step 2.4 in the Standard Pairing Process above, hold the top of your device over the buttons of your Controller to pair.

“How can one setup be controlled by multiple iOS users?”

This is accomplished with the Apple Home App and the Nanoleaf App.

Primary User

  • 1.1

    Open the Nanoleaf App.

  • 1.2

    Select the MORE tab.   · · ·

  • 1.3

    Select USERS.

  • 1.4

    Invite the secondary user with their email address.

Secondary User

  • 1.1

    A notification will appear for you to accept.

  • 1.2

    In the Home App, select the home icon in the top left.

  • 1.3

    Select HOME SETTINGS, a list of homes will appear.

  • 1.4

    Accept the home that has been shared with you. This will give you control of the Shapes as well as any other HomeKit devices in the same home.

Pairing Your Panels Android

Standard Pairing Process for Android

To ensure a smooth pairing process, please make sure you have the following things ready:

  • Requires Android 5.0+

  • Can be found on your Quick Start Guide, Controller or PSU.

  • 5 GHz networks are not compatible with Nanoleaf products.

  • The controller is ready when the Status LED is solid white.

1

Download and Open the Nanoleaf App

You can find the official Nanoleaf Smarter Series App in the Google Play Store. Make sure you have the latest version.

2

Pair Your Shapes

  • 2.1

    Ensure your location settings are turned on.

  • 2.2

    Select DEVICES, located in the side menu on the left.

  • 2.3

    Select + to add a device.

  • 2.4

    Select SHAPES as your product and choose one of the following options to pair:

  • 1. Scan the code in the Quick Start Guide, Controller or PSU

  • 1. Ensure that NFC is enabled.

    2. Hold the top of your device over the buttons of your Controller to pair.

  • 1. If you have more than one set of panels connected to your network, select the magnifying glass to identify the correct setup (it will flash green).

    2. Once identified, TAP TO PAIR.

    3. Enter your 8-digit pairing code (found on the Quick Start Guide, PSU or Controller).

Controlling Your Panels

Controller

The Controller is the brain of the Nanoleaf Shapes. The touch control buttons on the Controller provide convenient shortcuts to common commands. The Controller can be attached to any available linker slot in your layout.

  • Cycle through Default or Saved Rhythm Scenes.

  • The Controller comes with dozens of preloaded Scenes, use the shuffle button to cycle through them. Hold the Shuffle button to return to a previous random Scene.

  • Cycle through Default or Saved Color Scenes.

Advanced Button Controls

You can also use the Controller’s touch buttons for advanced commands—most commands can be executed by holding buttons, or tapping two buttons at once. Here is a full list of shortcuts:

  • Only the last 5 randomly loaded Scenes are available. A flash of yellow on the panels will indicate that you are at the end of your browsing history.

  • This saves the current Scene if it’s not already saved. This is most useful for saving Scenes you like when using.

  • Cycle through the following preset white light modes:

    Warm White (2700K),

    Reading Light (4000K),

    Daylight White (5000K).

  • If you have more than 20 panels connected to your Controller, this enables or disables Power Diagnostic Mode. This mode helps you place additional power supplies to optimize your Nanoleaf Shapes system.

  • This opens a 30s window to pair.

  • This mode allows your Controller to act as a local network hotspot without an Internet connection. With this mode active, you can use the Nanoleaf App to operate your Nanoleaf Shapes without needing a router or access point.

NOTE: During Wi-Fi Hospot Mode, your Controller will not be able to download firmware updates. Discover content from the community will also be unavailable.

Touch Actions

Touch Actions transform each light panel into a smart button, allowing for the most seamless control of your entire smart home. With as little as a single press on a panel, activate HomeKit Scenes to control any or all of your HomeKit products at once. See it in action here.

Touch Gestures

Touch Gestures can be used to change brightness, Scenes or turning your Shapes on and off. Find more about this function here.

The Nanoleaf App

Turn your lighting on and off, control brightness, group lights by home and by room, create and use Scenes, and much more.

  • Choose an existing Scene or create your own (Static, Dynamic, Rhythm, Group, Layered). You can also use the Paint Tool to color panels individually.

  • Find helpful information including tutorials, new device features, etc.

  • Find and download new Scenes created by the Nanoleaf community.

  • Automate your Scenes to turn on or off.

Nanoleaf Desktop App

With the Nanoleaf Desktop App, you can control your Panels from a web browser on your computer. Create and download new Scenes and set Schedules right from your computer. The Desktop App was designed to simplify the management of larger installations and offer control of many different layouts at once.

DOWNLOAD DESKTOP APP

Voice Control

You can easily control your Panels by voice in a few different ways. In the Nanoleaf App, make sure to name your panels something easy to say.

  • “Turn [Device Name] on/off.”

    “Set [Device Name] to 10% brightness.”

    “Set [Device Name] to [Scene Name]”

    “Brighten/dim the lights to [%].”

    “Set [Device Name] to [Color].”

    “Set [Scene Name].”

    “Brighten/dim the lights.”

  • “Turn on [Device Name or Scene Name].” “Turn on/off the lights in [Room Name].” “Turn on/off all my lights.”

    “Turn off [Device Name].”

    “Brighten/dim [Device Name].”

    “Brighten/dim the lights in [Room Name].” “Brighten/dim all my lights.”

    “Set [Device Name] to [%].”

    “Set [Device Name] to [Color].”

  • “Turn on [Device Name or Scene Name].” “Turn off [Device Name].”

    “Brighten/dim [Device Name].”

    “Set [Device Name] to [%] brightness.” “Set [Device Name] to [Color].”

Nanoleaf Remote

The optional Nanoleaf Remote accessory is a sleek, dodecahedron-inspired Bluetooth HomeKit remote designed to enhance the smarter home experience and make controlling the Nanoleaf Panels and other HomeKit products even more convenient. Available on the Nanoleaf Shop.

  • Control the brightness of your Panels by rotating the remote clockwise and counterclockwise.

  • Save your favorite Scenes to any of the twelve sides. Face up to activate.

Nanoleaf Open API

A local network API designed to extend your experience and allow you to integrate the Panels with third party devices and services, as well as enable more granular control of the hardware.

LOG IN
PROBLEMS & SOLUTIONS

Reset Options

1

Soft Reset

This will reset the Wi-Fi and all saved pairing configurations. Your saved scenes will remain.

  • 1.1

    Press and hold the Power and brighten buttons together on the Controller for 15 seconds.

  • 1.2

    Let go once the Status LED starts flashing.

  • 1.3

    Wait for the Power button LED to remain on and steady.

  • 1.4

    On the Nanoleaf App, delete the previous device and re-pair it again.

2

Hard Reset

This will reset your Shapes to factory settings, deleting Wi-Fi settings, pairing information, and saved scenes. Your default scenes and settings will be restored.

NOTE: You can restore your Scenes after a Hard Reset if you are logged in to your Nanoleaf Account (see Restore Scenes procedure below).

  • 2.1

    Unplug your Shapes from the power source.

  • 2.2

    While holding the Power and brighten buttons, plug the Power Supply back into power.

  • 2.3

    Continue holding the buttons down until the button LEDs on the Controller come on.

  • 2.4

    Once the LEDs come on, quickly release the buttons. The LEDs will flash to indicate that the hard reset will now take place.

  • 2.5

    Wait about 2 minutes for a reboot. The Shapes are ready to be setup once the Power Button LED turns on and the panels begin cycling through different colors.

*

Need to Restore Your Scenes?

Nanoleaf Panels

Requires Firmware 3.1.0+

Nanoleaf App

Requires Software 3.4+ for iOS & Android

  • 1.

    Open the Nanoleaf App.

  • 2.

    Login to your Nanoleaf Account.

  • 3.

    In the Dashboard tab, select the Settings icon.

  • 4.

    Under SYSTEM > BACKUP AND RESTORE, ensure that DEVICE SYNC is enabled.

  • 5.

    Select RESTORE FROM BACKUP and RESTORE.

Common Solutions

“I moved or changed my Wi-Fi network.”

  • A

    Try Wi-Fi Settings Reset

    This will allow you to connect your Shapes to a new Wi-FI network.

  • 1.

    Plug your Shapes in to a power source.

  • 2.

    With the Power and the Brighten buttons on the Controller, press and alternate between them 5 times (10 presses total).

  • 3.

    The Status LED will become a solid white.

    "

“My Shapes are paired but unreachable.”

  • A

    Try to Toggle your Wi-Fi

    On your phone, toggle the Wi-Fi off, then on again.

  • B

    Try to Power Cycle your Controller

    Unplug your controller from power, then plug it back in.

  • C

    Try to Power Cycle your Router

    On your phone, toggle the Wi-Fi off, then on again.

  • D

    Try a Soft Reset

“I am not able to pair my Shapes.”

  • A

    Check your Router Settings

  • 1.

    5 GHz networks do not support Nanoleaf products. Are you connected to a 2.4 GHz network?

  • 2.

    Ensure multicast, IGMP, UPnP (if available) are enabled on your router settings.

  • B

    Try a Soft Reset

  • C

    Try a Hard Reset

“I don’t see my Shapes in the App for setup.”

Wi-Fi Troubleshooting

Plug your PSU into power. The Power button on the Controller will light up after 1 minute.


If your Status LED is Solid White

Meaning: Your Shapes are ready to connect to your network.

  • 1.

    Make sure your mobile device Wi-Fi is on.

  • 2.

    Move your mobile device closer to your panels.

  • 3.

    Toggle the Wi-Fi on your mobile device off, then on.

  • 4.

    Try a Hard Reset.


If your Status LED is Flashing

Meaning: Your Wi-Fi is configured, but the panels cannot connect to the target network.

  • 1.

    Try to Power Cycle your Shapes (unplug your PSU from power, then plug it back in).

  • 2.

    If your panels are paired on the Nanoleaf App, delete the device and re-pair them with the Standard Pairing Process.


If your Status LED is Unlit

Meaning: Your Wi-Fi is configured and connected to your router.

  • 1.

    Make sure your mobile device is on the same network.

  • 2.

    Toggle the Wi-Fi on your mobile device off, then on.

Placement Tips

The following tips can help your Nanoleaf Shapes achieve the best wireless range & network reception.

  • 1.

    Place your Shapes in an open area where there are less obstructions, such as large pieces of furniture or walls.

  • 2.

    Avoid placing your Shapes behind furniture or inside cabinets.

  • 3.

    Don‘t place your Shapes in areas surrounded by metal surfaces on three or more sides. This can cause signal issues.

  • 4.

    Try to place your Shapes at least 25 feet (8 meters) away from any microwave oven, 2.4 GHz cordless phone, Wi-Fi devices, or other source of interference.

  • 5.

    Place your Shapes as close to your Wi-Fi home router as possible. For best performance, keep the distance below 65 feet (20 meters) and have no more than one wall in between.

Large Installations

1

Activate Power Diagnostic Mode

If you have more than 21 panels and/or multiple Controllers in your Shapes setup, you should try to distribute power supplies across your layout evenly. Activating Power Diagnostic Mode will give you tips on where you can place your power supplies for optimal performance. The options below will outline how this mode can be activated:

  • 1. On your Controller, hold the Dim (–) and Brighten (+) buttons down together for 5s.

    2. A color-coded map of your panels will appear. The map will automatically update as you connect or move, power supply units within your setup.

  • If your setup is already optimized, these warnings will not appear and Power Diagnostic Mode will be inaccessible. If you wish to enable Power Diagnostic Mode anyway, the button sequence on the Controller can be used see Option A).

  • 1. Open the MORE menu.

    2. Select SETTINGS > WARNINGS > Power Limited

  • 1. Open the side menu.

    2. Select SETTINGS > WARNINGS > Power Limited

Distribute Power Supply

  • Red: Power supply needs to be moved.

  • Green: Power supply is in good placement.

  • Blue: Number of missing Power Supplies and the best places for those supplies.

  • White: Alternative place to add a power supply. The brighter the panel, the better the placement.

2

Controlling Your Setup with Nanoleaf Tools

Nanoleaf Desktop App

With the Nanoleaf Desktop App, you can control your Shapes from a web browser on your computer. Create and download new Scenes and set Schedules right from your computer. The Desktop App was designed to simplify the management of larger installations and offer control of many different layouts at once.

DOWNLOAD DESKTOP APP

Nanoleaf Open API

A local network API designed to extend your product experience. Integrate your setup with third party devices and services and enable more granular control of the hardware.

LOG IN
Please Add Video Link
